ET6119

  • Product Introduction

Aviation Aluminum body.

Ultra white tempered glass.

Silicone gasket.

High efficiency PMMA lens.

Anti-corrosion electrostatic powder coating.

Stainless steel external screws and mounting plate.

Special surface treatment is required for special coastal environments.

Structurally waterproof, detachable for easy replacement of LED, lens, and driver.


Model Power Beam angle CCT Luminous flux Control SDCM CRI LED Voltage Weight
ET6119 11W*2 15°/24°/36°/50°/20°*50° 2700K/3000K/4000K/5000K 717lm*2(3000K 15°) ON/OFF 3 80 COB*2 220V-240V 3KG
  • Specifications
  • Download
  • Accessory

ET6119

Electrical and Control

Voltage 220V-240V
Power11W*2
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-20 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityCOB X 2
Beam Angle15° / 24° / 36° / 50° / 20°x50°
Delivered Lumen717lm*2(3000K 15°)
Colour RenderingCRI 80
SDCM3
CCT2700K / 3000K / 4000K / 5000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight3KG
Warranty3 years
RatingIP65
Impact ProtectionIK08
CertificationsCE


ET6119

Documents

ET6119

Optional accessories

  • Information
  • Downloads
  • Accessories
  • Service

71 025

DALI cross switch

DALI cross switch
sdsdsds

71 025

DALI cross switch

DALI cross switch
Documents

Product data sheet

Product data sheet

The technical specifications in the instructions for use, product data sheets and quotation texts refer to the products manufactured at the time of publication. We are constantly working to improve the performance and efficiency of our products. The goods delivered may therefore deviate slightly from those advertised.
