Die casting aluminum body.
Ultra white tempered glass.
Silicone gasket.
High efficiency PC lens.
Anti-corrosion electrostatic powder coating
Stainless steel external screws and mounting plate.
Structurally waterproof, detachable for easy replacement of LED, lens, and driver
Marine grade is also available, please contact sales to get details.
| Model | Power | Beam angle | CCT | Luminous flux | Control | SDCM | CRI | LED | Voltage | Weight |
|---|---|---|---|---|---|---|---|---|---|---|
| ET6868 | 14W | Asymmetric | 2700K/3000K/4000K | 684lm | ON/OFF | 5 | 80 | LEDx5 | 220V-240V | 3KG |
Electrical and Control
| Voltage | 220V-240V |
| Power | 14W |
| Power Supply | Built-in |
| Control | ON/OFF / 0-10V / DALI |
| Cable | 0.5M H05RN-F 3x1mm2 |
| Environmental | -20 °C ~ 50 °C |
LED and Optics
| LED Brand | CITIZEN / CREE |
| LED Quantity | LED X 5 |
| Beam Angle | Asymmetric |
| Delivered Lumen | 684lm |
| Colour Rendering | CRI 80 |
| SDCM | 5 |
| CCT | 2700K/3000K/4000K |
| LED Optic | PMMA Lens |
Physical
| Housing | Die-cast aluminum |
| Lens Material | Tempered glass |
| External Screw | Stainless steel material |
| Surface Treatment | Anticorrosive coating |
| Net Weight | 3KG |
| Warranty | 3 years |
| Rating | IP65 |
| Impact Protection | IK08 |
| Certifications | CE |
