ET6167

  • Product Introduction

Die casting aluminum body.

Ultra white tempered glass.

Silicone gasket.

High efficiency PC lens.

Anti-corrosion electrostatic powder coating

Stainless steel external screws and mounting plate.

Structurally waterproof, detachable for easy replacement of LED, lens, and driver

Marine grade is also available, please contact sales to get details.


Model Power Beam angle CCT Luminous flux Control SDCM CRI LED Voltage Weight
ET6167 7W Asymmetric 2700K/3000K/4000K 339lm ON/OFF 5 80 LEDx2 100V-240V 1.7KG
  • Specifications
  • Download
  • Accessory

ET6167

Electrical and Control

Voltage 220V-240V
Power7W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-20 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityLED X 2
Beam AngleAsymmetric
Delivered Lumen339lm
Colour RenderingCRI 80
SDCM5
CCT2700K/3000K/4000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight1.7KG
Warranty3 years
RatingIP65
Impact ProtectionIK08
CertificationsCE


ET6167

Documents

ET6167.IES

ET6167

Optional accessories
