ET6876

  • Product Introduction

Contemporary style wall pack in an angular, compact housing.

Types III and IV distributions with full cutoff ideally suited for architectural applications. Selectable wattage helps reduce inventory and accelerate delivery.

The product adopts a reversible fixed structure, with the installation base and lighting fixtures integrated, making construction and  installation more convenient.

Some lights can be connected with EPS to extend working for 3  hours during power off or outage.

Anti-corrosive electrostatic powder coating.

Marine grade is also available, please contact sales to get details.


Model Power Beam angle CCT Luminous flux Control SDCM CRI LED Voltage Weight
ET6876 47W TYPE III-S / TYPE IV-S 2700K/3000K/4000K 4911lm（TYPE II-S 3000K） ON/OFF 5 80 SMDx72 100V-240V 4.4KG
  • Specifications
  • Download
  • Accessory

ET6876

Electrical and Control

Voltage 100V-240V
Power47W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-40 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantitySMDx72
Beam AngleTYPE III-S / TYPE IV-S
Delivered Lumen4911lm（TYPE II-S  3000K）
Colour RenderingCRI 80
SDCM5
CCT2700K/3000K/4000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight4.4KG
Warranty3 years
RatingIP65
Impact ProtectionIK08
CertificationsCE
