ET6875

  • 产品信息

Contemporary style wall pack in an angular, compact housing.

Types III and IV distributions with full cutoff ideally suited for architectural applications. Selectable wattage helps reduce inventory and accelerate delivery.

The product adopts a reversible fixed structure, with the installation base and lighting fixtures integrated, making construction and  installation more convenient.

Some lights can be connected with EPS to extend working for 3  hours during power off or outage.

Anti-corrosive electrostatic powder coating.

Marine grade is also available, please contact sales to get details.


型号 功率 角度 色温 流明 控制方式 色容差 显色指数 LED 电压 重量
ET6875 III-S 23W TYPE III-S / TYPE IV-S 2700K / 3000K / 4000K 2142lm ON / OFF 5 80 SMD*36 100V - 240V 3.2KG
  • 规格
  • 下载
  • 配件

ET6875 III-S

Electrical and Control

Voltage 100V-240V
Power23W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-40 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantitySMD X 36
Beam AngleTYPE III-S / TYPE IV-S
Delivered Lumen2142lm (3000K TYPE III-S)
Colour RenderingCRI 80
SDCM5
CCT2700K / 3000K / 4000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight3.2KG
Warranty3 years
RatingIP65
Impact ProtectionIK08
CertificationsCE




ET6875 III-S

ET6875 III-S

可选配件

  • Information
  • Downloads
  • Accessories
  • Service

71 025

DALI cross switch

DALI cross switch
sdsdsds

71 025

DALI cross switch

DALI cross switch
下载

Product data sheet

Product data sheet

The technical specifications in the instructions for use, product data sheets and quotation texts refer to the products manufactured at the time of publication. We are constantly working to improve the performance and efficiency of our products. The goods delivered may therefore deviate slightly from those advertised.
