ET7153

  • Product Introduction

A type of entirely stainless steel floodlight,which can be either used for dry or wet harsh outdoor environments.

Exquisite brushed housing surface. Fin design ensures better heat dissipation. Stainless steel 316L housing High transmittance, tempered glass without light shifting ensures consistency of CCT of LEDs.

Stainless steel exposed screws and mounting bracket.

Suitable for waterscape and some harsh environmental landscape lighting.


Model Power Beam angle CCT Luminous flux Control SDCM CRI LED Voltage Weight
ET7153 6W 15° / 24° / 36° / 50°/ 20°*50° 2700K / 3000K / 4000K / 5000K 434lm(3000K 24°) ON IOFF 3 80 COBx1 24VDC 1.2KG
  • Specifications
  • Download
  • Accessory

ET7153

Electrical and Control

Voltage 24VDC
Power6W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-20 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityCOB X 1
Beam Angle15° / 24° / 36° / 50° / 20°x50°
Delivered Lumen434lm (3000K 24°)
Colour RenderingCRI 80
SDCM3
CCT2700K / 3000K / 4000K / 5000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight1.2KG
Warranty3 years
RatingIP68
Impact ProtectionIK09
CertificationsCE



ET7153

Documents

ET7153.IES
