ET7032

  • Product Introduction

Die casting aluminum body and faceplate.

Ultra white tempered glass.

Silicone gasket.

High efficiency PMMA lens.

Anti-corrosion electrostatic powder coating.

External screws are all made of stainless steel materials.

The projecting angle can be 90°adjusted .

Marine grade treatment is available for seaside environments.

Structure waterproof, all components can be disassembled and replaced.

Moisture-prevention designed inside.


Model Power Beam angle CCT Luminous flux Control SDCM CRI LED Voltage Weight
ET7032 100W 10° / 20° / 50° / 90° / TYPE III 2700K / 3000K / 4000K 6974lm(3000K 20°) ON / OFF 5 80 LEDx40 100V-240V 6.7KG
  • Specifications
  • Download
  • Accessory

ET7032

Electrical and Control

Voltage 100V-240V
Power100W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-40 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityLED X 40
Beam Angle10° / 20° / 50° / 90° / TYPE III
Delivered Lumen6974lm (3000K 20°)
Colour RenderingCRI 80
SDCM5
CCT2700K / 3000K / 4000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight6.7KG
Warranty3 years
RatingIP65
Impact ProtectionIK08
CertificationsCE



ET7032

Documents

ET7032.IES
