Die casting aluminum body and faceplate.
Ultra white tempered glass. Silicone gasket.
High efficiency PMMA lens.
Anti-corrosion electrostatic powder coating.
External screws are all made of stainless steel materials.
The projecting angle can be 90°adjusted .
Marine grade treatment is available for seaside environments.
Structure waterproof, all components can be disassembled and replaced.
Moisture-prevention designed inside.
| Model | Power | Beam angle | CCT | Luminous flux | Control | SDCM | CRI | LED | Voltage | Weight |
|---|---|---|---|---|---|---|---|---|---|---|
| ET7054 | 10W | 15° / 24° / 36° / 50° / 20°*50° | 2700K / 3000K / 4000K / 5000K | 911lm(3000K 24°) | ON / OFF | 3 | 80 | COBx1 | 220V - 240V | 1.2KG |
Electrical and Control
| Voltage | 220V-240V |
| Power | 10W |
| Power Supply | Built-in |
| Control | ON/OFF / 0-10V / DALI |
| Cable | 0.5M H05RN-F 3x1mm2 |
| Environmental | -20 °C ~ 50 °C |
LED and Optics
| LED Brand | CITIZEN / CREE |
| LED Quantity | COB X 1 |
| Beam Angle | 15° / 24° / 36° / 50° / 20°*50° |
| Delivered Lumen | 911lm(3000K 24°) |
| Colour Rendering | CRI 80 |
| SDCM | 3 |
| CCT | 2700K / 3000K / 4000K / 5000K |
| LED Optic | PMMA Lens |
Physical
| Housing | Die-cast aluminum |
| Lens Material | Tempered glass |
| External Screw | Stainless steel material |
| Surface Treatment | Anticorrosive coating |
| Net Weight | 1.2KG |
| Warranty | 3 years |
| Rating | IP65 |
| Impact Protection | IK08 |
| Certifications | CE |
