Compact Landscape Light.
Die casting aluminum body.
Ultra white tempered glass.
Silicone gasket.
High efficiency PMMA lens.
Anti-corrosion electrostatic powder coating.
Stainless steel external screws and mounting plate.
Vertically ± 90 ° adjust and horizontally 360 ° rotate.
Special surface treatment is required for coastal environments.
Structurally waterproof, detachable for easy maintenance of LED, lens, shroud and driver.
| Model | Power | Beam angle | CCT | Luminous flux | Control | SDCM | CRI | LED | Voltage | Weight |
|---|---|---|---|---|---|---|---|---|---|---|
| ET7048 | 11W | 15°/24°/36°/50°/20°*50° | 2700K/3000K/4000K/5000K | 811lm(3000K 15°) | ON/OFF | 3 | 80 | COBx1 | 24VDC | 0.8KG |
Electrical and Control
| Voltage | 24VDC |
| Power | 11W |
| Power Supply | Built-in |
| Control | ON/OFF / 0-10V / DALI |
| Cable | 0.5M H05RN-F 3x1mm2 |
| Environmental | -20 °C ~ 50 °C |
LED and Optics
| LED Brand | CITIZEN / CREE |
| LED Quantity | COB X 1 |
| Beam Angle | 15°/24°/36°/50°/20°*50° |
| Delivered Lumen | 811lm(3000K 15°) |
| Colour Rendering | CRI 80 |
| SDCM | 3 |
| CCT | 2700K / 3000K / 4000K / 5000K |
| LED Optic | PMMA Lens |
Physical
| Housing | Die-cast aluminum |
| Lens Material | Tempered glass |
| External Screw | Stainless steel material |
| Surface Treatment | Anticorrosive coating |
| Net Weight | 0.8KG |
| Warranty | 3 years |
| Rating | IP65 |
| Impact Protection | IK08 |
| Certifications | CE |
