ET6890

  • 产品信息

Aviation Aluminum body, tough and super high performance of heat dissipation.

Ultra white tempered glass.

Silicone gasket.

High efficiency PMMA lens.

First surface brushed treatment and then spraying plastics.

Anti-corrosive electrostatic powder coating.

Stainless steel external screws and mounting brackets

Special surface treatment is required for special coastal environments.

The product is waterproof and sealed with sealing compound.

Different lengths are available by customization.



型号 功率 角度 色温 流明 控制方式 色容差 显色指数 LED 电压 重量
ET6890.RGBW 48W 15°*40° 2700K / 3000K / 4000K/ 5000K DMX512 80 LEDx24 24VDC 1.5KG
ET6890 48W 10°/15°/30°/45°/60°/15°*50° 2700K / 3000K / 4000K/ 5000K 3323lm（3000K 10°） ON/OFF 5 80 LEDx24 24VDC 1.5KG
  • 规格
  • 下载
  • 配件

ET6890.RGBW

Electrical and Control

Voltage24VDC
Power48W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-40 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityLEDx24
Beam Angle15°*40°
Delivered Lumen
Colour RenderingCRI 80
SDCM
CCT2700K / 3000K / 4000K/ 5000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight1.5KG
Warranty3 years
RatingIP65
Impact ProtectionIK08
CertificationsCE


ET6890.RGBW

文件

ET6890.RGBW

可选配件

  • 规格
  • 下载
  • 配件

ET6890

Electrical and Control

Voltage24VDC
Power48W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-40 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityLEDx24
Beam Angle10°/15°/30°/45°/60°/15°*50°
Delivered Lumen3323lm（3000K 10°）
Colour RenderingCRI 80
SDCM5
CCT2700K / 3000K / 4000K/ 5000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight1.5KG
Warranty3 years
RatingIP65
Impact ProtectionIK08
CertificationsCE


ET6890

文件

ET6890

可选配件
