ET6806

  • Product Introduction

Aviation Aluminum body, tough and super high performance of heat dissipation.

Ultra white tempered glass.

Silicone gasket.

High efficiency PMMA lens.

First surface brushed treatment and then spraying plastics.

Anti-corrosive electrostatic powder coating.

Stainless steel external screws and mounting brackets

Special surface treatment is required for special coastal environments.

The product is waterproof and sealed with sealing compound.

Different lengths are available by customization.


Model Power Beam angle CCT Luminous flux Control SDCM CRI LED Voltage Weight
ET6806 30W 18°/30°/45°/60°/20°*45° 2700K / 3000K / 4000K/5000K 1886lm(3000 18°) ON/OFF 5 80 LEDx24 24VDC 1.3KG
  • Specifications
  • Download
  • Accessory

ET6806

Electrical and Control

Voltage24VDC
Power30W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-40 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED Quantity LED X 24
Beam Angle18°/30°/45°/60°/20°*45°
Delivered Lumen1886lm(3000 18°)
Colour RenderingCRI 80
SDCM5
CCT2700K / 3000K / 4000K/ 5000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight1.3KG
Warranty3 years
RatingIP65
Impact ProtectionIK08
CertificationsCE


ET6806

Documents

ET6806

Optional accessories
