ET6607

  • 产品信息

Aviation Aluminum body, tough and super high performance of heat dissipation.

Ultra white tempered glass.

Silicone gasket.

High efficiency PMMA lens.

First surface brushed treatment and then spraying plastics.

Anti-corrosive electrostatic powder coating.

Stainless steel external screws and mounting brackets

Special surface treatment is required for special coastal environments.

The product is waterproof and sealed with sealing compound.

Different lengths are available by customization.



型号 功率 角度 色温 流明 控制方式 色容差 显色指数 LED 电压 重量
ET6607 12W 120° 2700K / 3000K / 4000K / 5000K 505lm ON/OFF 5 80 SMDx48 24VDC 3.2KG
  • 规格
  • 下载
  • 配件

ET6607

Electrical and Control

Voltage24VDC
Power12W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-40 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantitySMD X 48
Beam Angle120°
Delivered Lumen505lm
Colour RenderingCRI 80
SDCM5
CCT2700K / 3000K / 4000K / 5000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight3.2KG
Warranty3 years
RatingIP65
Impact ProtectionIK06
CertificationsCE


ET6607
