ET2300

  • 产品信息

Die casting aluminum body and faceplate.

Ultra white tempered glass.

Silicone gasket.

Anti-corrosion electrostatic powder coating.

Stainless steel external screws and mounting plate.

Strengthened PP or SS preinstall box.

Design of structural heat dissipation.

On/off standard and 0-10V.

The light can be installed on pillar, wall or side of stais according to it's size.

Can be used to indicate or light on small path or ground area, no risks to  public for it's recessed mounting design.


型号 功率 角度 色温 流明 控制方式 色容差 显色指数 LED 电压 重量
ET2300 10W 100° 2700K / 3000K / 4000K 160lm ON/OFF 7 80 SMDx48 100V-240V 1.1Kg
  • 规格
  • 下载
  • 配件

ET2300

Electrical and Control

Voltage100V-240V
Power10W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.3M H05RN-F 3x1mm2
Environmental                                                                                        -20 °C ~ 50 °C


LED and Optics

LED BrandOSRAM
LED QuantitySMDx48
Beam Angle100°
Delivered Lumen160lm
Colour RenderingCRI 80
SDCM7
CCT2700K / 3000K / 4000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight1.1KG
Warranty3 years
RatingIP65
Impact ProtectionIK06
CertificationsCE



ET2300
