ET2212

  • Product Introduction

Die casting aluminum body and faceplate.

Ultra white tempered glass.

Silicone gasket.

Anti-corrosion electrostatic powder coating.

Stainless steel external screws and mounting plate.

Strengthened PP or SS preinstall box.

Design of structural heat dissipation.

On/off standard and 0-10V.

The light can be installed on pillar, wall or side of stais according to it's size.

Can be used to indicate or light on small path or ground area, no risks to  public for it's recessed mounting design.

Model Power Beam angle CCT Luminous flux Control SDCM CRI LED Voltage Weight
ET2212 14W 360° 2700K / 3000K / 4000K 890lm ON/OFF 5 80 LEDx6 100V-240V 1Kg
  • Specifications
  • Download
  • Accessory

ET2212

Electrical and Control

Voltage 100V-240V
Power14W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.3M H05RN-F 3x1mm2
Environmental                                                                                        -20 °C ~ 50 °C


LED and Optics

LED BrandCREE
LED QuantityLEDx6
Beam Angle360°
Delivered Lumen890lm
Colour RenderingCRI 80
SDCM5
CCT2700K / 3000K / 4000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight1KG
Warranty3 years
RatingIP65
Impact ProtectionIK08
CertificationsCE



ET2212

Documents

ET2212

ET2212

Optional accessories

  • Information
  • Downloads
  • Accessories
  • Service

71 025

DALI cross switch

DALI cross switch
sdsdsds

71 025

DALI cross switch

DALI cross switch
Documents

Product data sheet

Product data sheet

The technical specifications in the instructions for use, product data sheets and quotation texts refer to the products manufactured at the time of publication. We are constantly working to improve the performance and efficiency of our products. The goods delivered may therefore deviate slightly from those advertised.
