ET9306

  • Product Introduction

Underwater Wall Washer Lights

Stainless steel body.

Ultra white tempered glass.

Silicone gasket.

High efficiency PMMA lens.

Stainless steel external screws and mounting bracket.

Specialized anti-water&vapour wiring.

Design of structural waterproof, durable and long lifetime.


Model Power Beam angle CCT Luminous flux Control SDCM CRI LED Voltage Weight
ET9306 27W 8° / 15° / 30° / 45° / 60° / 10°*60° 2700K / 3000K / 4000K / 5000K 1323lm(3000K 8°) ON/OFF 5 80 LEDx18 12VDC 4.8Kg
  • Specifications
  • Download
  • Accessory

ET9306

Electrical and Control

Voltage12VDC
Power27W
Power SupplyRemote
ControlON/OFF / 0-10V / DALI
Cable1M H05RN-F 3x1mm2
Environmental                                                                                        -40 °C ~ 50 °C


LED and Optics

LED BrandCREE
LED QuantityLEDx18
Beam Angle8° / 15° / 30° / 45° / 60° / 10°*60°
Delivered Lumen1323lm(3000K 8°)
Colour RenderingCRI 80
SDCM5
CCT2700K / 3000K / 4000K / 5000K
LED OpticPMMA Lens


Physical

HousingStainless steel material
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight4.8KG
Warranty3 years
RatingIP68
Impact ProtectionIK09
CertificationsCE



ET9306

Documents

ET9306

ET9306

Optional accessories
