Trimless round in-ground uplighter
Stainless steel body.
Tempered glass.
Silicone gasket.
High efficiency PMMA lens.
Stainless steel external screws .
Strengthened PP mounting sleeve .
High Power LED chips, constant current driver, line voltage input.
On/off standard, DALI , 0-10V or Traic dimming is optional.
Specialized anti-water&vapour wiring.
| Model | Power | Beam angle | CCT | Luminous flux | Control | SDCM | CRI | LED | Voltage | Weight |
|---|---|---|---|---|---|---|---|---|---|---|
| ET8356 | 10W | 15°/24°/36°/50°/20°*50° | 2700K / 3000K / 4000K / 5000K | 825lm(3000K 15°) | ON/OFF | 3 | 80 | COBx1 | 24VDC | 1.2KG |
Electrical and Control
| Voltage | 24VDC |
| Power | 10W |
| Power Supply | Built-in |
| Control | ON/OFF / 0-10V / DALI |
| Cable | 0.5M H05RN-F 3x1mm2 |
| Environmental | -40 °C ~ 50 °C |
LED and Optics
| LED Brand | CITIZEN / CREE |
| LED Quantity | COB X 1 |
| Beam Angle | 15°/24°/36°/50°/20°*50° |
| Delivered Lumen | 825lm |
| Colour Rendering | CRI 80 |
| SDCM | 3 |
| CCT | 2700K / 3000K / 4000K / 5000K |
| LED Optic | PMMA Lens |
Physical
| Housing | Die-cast aluminum |
| Lens Material | Tempered glass |
| External Screw | Stainless steel material |
| Surface Treatment | Anticorrosive coating |
| Net Weight | 1.2 KG |
| Warranty | 3 years |
| Rating | IP68 |
| Impact Protection | IK10 |
| Certifications | CE |
