ET8830

  • Product Introduction

Trimless round in-ground uplighter

Stainless steel body.

Tempered glass.

Silicone gasket.

High efficiency PMMA lens.

Stainless steel external screws.

Strengthened PP mounting sleeve .

High Power LED chips, constant current driver, line voltage input.

On/off standard, DALI , 0-10V or Traic dimming is optional.

Specialized anti-water&vapour wiring



Model Power Beam angle CCT Luminous flux Control SDCM CRI LED Voltage Weight
ET8830 0.5W 120° 2700K / 3000K / 4000K / 6000K 15lm ON/OFF 7 80 SMDx6 24VDC 0.6KG
  • Specifications
  • Download
  • Accessory

ET8830

Electrical and Control

Voltage24VDC
Power0.5W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-20 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantitySMD X 6
Beam Angle120°
Delivered Lumen15lm
Colour RenderingCRI 80
SDCM7
CCT2700K / 3000K / 4000K / 6000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight0.6 KG
Warranty3 years
RatingIP68
Impact ProtectionIK10
CertificationsCE


ET8830

Documents

ET8830

Optional accessories

  • Information
  • Downloads
  • Accessories
  • Service

71 025

DALI cross switch

DALI cross switch
sdsdsds

71 025

DALI cross switch

DALI cross switch
Documents

Product data sheet

Product data sheet

The technical specifications in the instructions for use, product data sheets and quotation texts refer to the products manufactured at the time of publication. We are constantly working to improve the performance and efficiency of our products. The goods delivered may therefore deviate slightly from those advertised.
