In-ground luminaires——stainless steel
Adopting an asymmetric polarized optical design scheme, utilizing LED light source and reflector to illuminate each other and achieve the principle of luminescence.
Asymmetric light distribution, maximum lighting usage and efficiency is improved greatly.
The family series products are all asymmetric light distribution, lighting distribution gets higher along with the distance from the wall.
This product is suitable for uniform light distribution on large area wall, and can be installed in crowded places.
Stainless steel body and mounting sleeve.
Ultra white tempered glass.
Silicone gasket.
High efficiency PMMA lens.
Stainless steel external screws and mounting plate.
| Model | Power | Beam angle | CCT | Luminous flux | Control | SDCM | CRI | LED | Voltage | Weight |
|---|---|---|---|---|---|---|---|---|---|---|
| ET8848 | 6W | Asymmetric | 2700K / 3000K / 4000K / 5000K | 270lm | ON/OFF | 3 | 80 | COBx1 | 220V-240V | 2.5KG |
Electrical and Control
| Voltage | 24VDC |
| Power | 6W |
| Power Supply | Built-in |
| Control | ON/OFF / 0-10V / DALI |
| Cable | 0.5M H05RN-F 3x1mm2 |
| Environmental | -20 °C ~ 50 °C |
LED and Optics
| LED Brand | CITIZEN / CREE |
| LED Quantity | COB X 1 |
| Beam Angle | Asymmetric |
| Delivered Lumen | 270lm |
| Colour Rendering | CRI 80 |
| SDCM | 3 |
| CCT | 2700K / 3000K / 4000K / 5000K |
| LED Optic | PMMA Lens |
Physical
| Housing | Die-cast aluminum |
| Lens Material | Tempered glass |
| External Screw | Stainless steel material |
| Surface Treatment | Anticorrosive coating |
| Net Weight | 2.5 KG |
| Warranty | 3 years |
| Rating | IP68 |
| Impact Protection | IK10 |
| Certifications | CE |
