ET8827

  • Product Introduction

Trimless design, good concealment, all stainless steel material.

The product is suitable for landscape lighting such as squares, corridors,  steps, water pools sculptures, etc.

Stainless steel body.

Ultra white tempered glass.

Silicone gasket.

High efficiency PMMA lens.

Stainless steel external screws.

Moisutre-prevention designation.

IP68 protection, professional outdoor design for cable configuration with water and moisture resistance.

Can not be used on lanes subjected to horizontal stress caused by acceleration, braking, and/or directional changes.

The pre-installa box needs to be flush with the decorative surface.

The wiring connectors between the main power supply and the lighting fixtures must be  waterproof.

To achieve IP68 waterproof rating to prevent circuit instability caused by water leakage.

Sucker is needed to take the fixture out from mounting sleeve.

Model Power Beam angle CCT Luminous flux Control SDCM CRI LED Voltage Weight
ET8827 2W 10°/15°/22°/45°/60°/15°*55° 2700K / 3000K / 4000K / 6000K 141lm(3000K 15°) ON/OFF 5 80 COBx1 24VDC 0.5KG
  • Specifications
  • Download
  • Accessory

ET8827

Electrical and Control

Voltage24VDC
Power2W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-40 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityCOB X 1
Beam Angle10°/15°/22°/45°/60°/15°*55°
Delivered Lumen141lm
Colour RenderingCRI 80
SDCM5
CCT2700K / 3000K / 4000K / 6000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight0.5 KG
Warranty3 years
RatingIP68
Impact ProtectionIK10
CertificationsCE
