ET8581

  • Product Introduction

Trimless design, evenly lighting distribution. Capable to get multiple colors and patterns.

Suitable for the surrounding square, road guidance, combination patterns and other land scape cultural travel light art display.

Aviation aluminum alloy profile lamp body.

High efficiency PMMA lens.

Aviation aluminum mounting sleeve.

Moisture-prevention designation, 24VDC power supply.


Model Power Beam angle CCT Luminous flux Control SDCM CRI LED Voltage Weight
ET8581 15W 120° 2700K / 3000K / 4000K / 5000K 152lm ON/OFF 7 80 LEDx96 24VDC 3.4KG
  • Specifications
  • Download
  • Accessory

ET8581

Electrical and Control

Voltage24VDC
Power15W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-40 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityLED X 96
Beam Angle120°
Delivered Lumen152lm
Colour RenderingCRI 80
SDCM5
CCT2700K / 3000K / 4000K / 5000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight3.4 KG
Warranty3 years
RatingIP67
Impact ProtectionIK10
CertificationsCE


ET8581

Documents

ET8581.IES

ET8581

Optional accessories
