ET8578

  • Product Introduction

Trimless design, evenly lighting distribution. Capable to get multiple colors and patterns.

Suitable for the surrounding square, road guidance, combination patterns and other land scape

cultural travel light art display.

Aviation aluminum alloy profile lamp body.

High efficiency PMMA lens.

Aviation aluminum mounting sleeve.

Moisture-prevention designation, 24VDC power supply.


Model Power Beam angle CCT Luminous flux Control SDCM CRI LED Voltage Weight
ET8578 4.5W 120° 2700K / 3000K / 4000K / 5000K 50lm ON/OFF 7 80 LEDx24 24VDC 0.9KG
  • Specifications
  • Download
  • Accessory

ET8578

Electrical and Control

Voltage 24VDC
Power4.5W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-40 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityLED X 24
Beam Angle120°
Delivered Lumen50lm
Colour RenderingCRI 80
SDCM7
CCT2700K / 3000K / 4000K / 5000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight0.9KG
Warranty3 years
RatingIP65
Impact ProtectionIK10
CertificationsCE
