ET8575

  • Product Introduction

Trimless design, evenly lighting distribution. Capable to get multiple colors and

patterns.

Suitable for the surrounding square, road guidance, combination patterns and other

land scape cultural travel light art display.

Stainless steel body.

Epoxy resin waterproof luminescent surface.

Stainless steel mounting sleeve.

Moisture-prevention designation, 24VDC power supply


Model Power Beam angle CCT Luminous flux Control SDCM CRI LED Voltage Weight
ET8575 4.5W 120° 2700K / 3000K / 4000K / 5000K 50lm ON/OFF 7 80 LEDx12 24VDC 2KG
  • Specifications
  • Download
  • Accessory

ET8575

Electrical and Control

Voltage24VDC
Power8W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-40 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityLED X12
Beam Angle120°
Delivered Lumen50lm
Colour RenderingCRI 80
SDCM7
CCT2700K / 3000K / 4000K / 5000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight2 KG
Warranty3 years
RatingIP67
Impact ProtectionIK10
CertificationsCE


ET8575

Documents

ET8575.IES

ET8575

Optional accessories

  • Information
  • Downloads
  • Accessories
  • Service

71 025

DALI cross switch

DALI cross switch
sdsdsds

71 025

DALI cross switch

DALI cross switch
Documents

Product data sheet

Product data sheet

The technical specifications in the instructions for use, product data sheets and quotation texts refer to the products manufactured at the time of publication. We are constantly working to improve the performance and efficiency of our products. The goods delivered may therefore deviate slightly from those advertised.
