ET8535

  • Product Introduction

Die casting aluminum body.

Can be selected 316 stainless steel decorative bezel.

Ultra white tempered glass.

Silicone gasket.

High efficiency PMMA lens.

Electrostatic powder coating.

The exposed screws are stainless steel.

Strengthened PP mounting sleeve.

Optional anti-glaring louver, The products are suitable for square,

building, sculpture, green belt, trees and other landscape lighting.


Model Power Beam angle CCT Luminous flux Control SDCM CRI LED Voltage Weight
ET8535 42W 8°/12°/22°/35°/45°/15°*45° 2700K / 3000K / 4000K / 5000K 2234lm(3000K 12°) ON/OFF 5 80 LEDx36 220V-240V 6KG
  • Specifications
  • Download
  • Accessory

ET8535

Electrical and Control

Voltage220V-240V
Power60W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-30 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityLED X36
Beam Angle8°/12°/22°/35°/45°/15°*45°
Delivered Lumen2234lm
Colour RenderingCRI 80
SDCM5
CCT2700K / 3000K / 4000K / 5000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight6 KG
Warranty3 years
RatingIP67
Impact ProtectionIK10
CertificationsCE


ET8535

Documents

ET8535

Optional accessories
