Die casting aluminum body.
Can be selected 316 stainless steel decorative bezel.
Ultra white tempered glass.
Silicone gasket.
High efficiency PMMA lens.
Electrostatic powder coating.
The exposed screws are stainless steel.
Strengthened PP mounting sleeve.
Optional anti-glaring louver, The products are suitable for square,
building, sculpture, green belt, trees and other landscape lighting.
| Model | Power | Beam angle | CCT | Luminous flux | Control | SDCM | CRI | LED | Voltage | Weight |
|---|---|---|---|---|---|---|---|---|---|---|
| ET8533 | 30W | 8°/12°/22°/35°/45°/15°*45° | 2700K / 3000K / 4000K / 5000K | 2234lm(3000K 12°) | ON/OFF | 5 | 80 | LEDx24 | 220V-240V | 5.5KG |
Electrical and Control
| Voltage | 220V-240V |
| Power | 30W |
| Power Supply | Built-in |
| Control | ON/OFF / 0-10V / DALI |
| Cable | 0.5M H05RN-F 3x1mm2 |
| Environmental | -30 °C ~ 50 °C |
LED and Optics
| LED Brand | CITIZEN / CREE |
| LED Quantity | LED X36 |
| Beam Angle | 8°/12°/22°/35°/45°/15°*45° |
| Delivered Lumen | 2234lm |
| Colour Rendering | CRI 80 |
| SDCM | 5 |
| CCT | 2700K / 3000K / 4000K / 5000K |
| LED Optic | PMMA Lens |
Physical
| Housing | Die-cast aluminum |
| Lens Material | Tempered glass |
| External Screw | Stainless steel material |
| Surface Treatment | Anticorrosive coating |
| Net Weight | 5.5 KG |
| Warranty | 3 years |
| Rating | IP67 |
| Impact Protection | IK10 |
| Certifications | CE |
