Using a specially designed multiple reflection principle, the light is efficiently emitted in anasymmetric direction to achieve uniform wall cleaning and anti glare effects.
The product is suitable for installation in key lighting applications such as corridors, walls, andsculptures.
Aluminium alloy lamp body.
Stainless steel decorative bezel, 316 stainless steel can be selected.
Ultra white tempered glass.
Silicone gasket.
High efficiency PMMA lens.
Surface double electrostatic powder coating..
Special vacuum coating reflector.
Mounting plate and stainless steel external screws.
Strengthened PP mounting sleeve.
| Model | Power | Beam angle | CCT | Luminous flux | Control | SDCM | CRI | LED | Voltage | Weight |
|---|---|---|---|---|---|---|---|---|---|---|
| ET8140 | 16W | Asymmetric | 2700K / 3000K / 4000K / 5000K | 1040lm | ON/OFF | 3 | 80 | COBx1 | 220V-240V | 4.7KG |
Electrical and Control
| Voltage | 220V-240V |
| Power | 16W |
| Power Supply | Built-in |
| Control | ON/OFF / 0-10V / DALI |
| Cable | 0.5M H05RN-F 3x1mm2 |
| Environmental | -20 °C ~ 50 °C |
LED and Optics
| LED Brand | CITIZEN / CREE |
| LED Quantity | COB X 1. |
| Beam Angle | Asymmetric |
| Delivered Lumen | 1040lm |
| Colour Rendering | CRI 80 |
| SDCM | 3 |
| CCT | 2700K / 3000K / 4000K / 5000K |
| LED Optic | PMMA Lens |
Physical
| Housing | Die-cast aluminum |
| Lens Material | Tempered glass |
| External Screw | Stainless steel material |
| Surface Treatment | Anticorrosive coating |
| Net Weight | 4.7KG |
| Warranty | 3 years |
| Rating | IP67 |
| Impact Protection | IK10 |
| Certifications | CE |
