ET8834

  • Product Introduction

Using a specially designed multiple reflection principle, the light is efficiently emitted in anasymmetric direction to achieve uniform wall cleaning and anti glare effects.

The product is suitable for installation in key lighting applications such as corridors, walls, andsculptures.

Aluminium alloy lamp body.

Stainless steel decorative bezel, 316 stainless steel can be selected.

Ultra white tempered glass.

Silicone gasket.

High efficiency PMMA lens.

Surface double electrostatic powder coating..

Special vacuum coating reflector.

Mounting plate and stainless steel external screws.

Strengthened PP mounting sleeve.


Model Power Beam angle CCT Luminous flux Control SDCM CRI LED Voltage Weight
ET8834 10W Asymmetric 2700K / 3000K / 4000K / 5000K 490lm ON/OFF 3 80 COBx1 220V-240V 1.2KG
  • Specifications
  • Download
  • Accessory

ET8834

Electrical and Control

Voltage 220V-240V
Power10W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-20 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityCOB X 1.
Beam Angle Asymmetric
Delivered Lumen490lm
Colour RenderingCRI 80
SDCM3
CCT2700K / 3000K / 4000K / 5000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight1.2KG
Warranty3 years
RatingIP67
Impact ProtectionIK10
CertificationsCE


ET8834

Documents

ET8834.IES

ET8834

Optional accessories

  • Information
  • Downloads
  • Accessories
  • Service

71 025

DALI cross switch

DALI cross switch
sdsdsds

71 025

DALI cross switch

DALI cross switch
Documents

Product data sheet

Product data sheet

The technical specifications in the instructions for use, product data sheets and quotation texts refer to the products manufactured at the time of publication. We are constantly working to improve the performance and efficiency of our products. The goods delivered may therefore deviate slightly from those advertised.
