ET8037

  • Product Introduction

This is a compact lighting fixture installed on a paved surface, suitable for both outdoor and indoor use.

The light can be directly illuminated to the road surface, no upward light, no glare, suitable for illuminating roads, paths, steps and some hidden places that need to be illuminated.

Aluminum die-cast lamp body and stainless steel lamp body (ф165mm products).

Aluminum die-cast light cover or stainless steel light cover.

Ultra white tempered glass.

Silicone gasket.

High efficiency PMMA lens.

Anti-corrosion electrostatic powder coating.

Mounting plate and stainless steel external screws.

Strengthened PP mounting sleeve.

Internal special air blocking waterproof cable.


Model Power Beam angle CCT Luminous flux Control SDCM CRI LED Voltage Weight
ET8037 4W 90° 2700K / 3000K / 4000K / 5000K 19lm ON/OFF 3 80 COBx1 100V-240V 0.78KG
  • Specifications
  • Download
  • Accessory

ET8037

Electrical and Control

Voltage100V-240V
Power4W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-30 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityCOB X 1
Beam Angle90°
Delivered Lumen19lm
Colour RenderingCRI 80
SDCM3
CCT2700K / 3000K / 4000K / 5000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight0.78 KG
Warranty3 years
RatingIP67
Impact ProtectionIK10
CertificationsCE


ET8037

Documents

ET8037

Optional accessories

  • Information
  • Downloads
  • Accessories
  • Service

71 025

DALI cross switch

DALI cross switch
sdsdsds

71 025

DALI cross switch

DALI cross switch
Documents

Product data sheet

Product data sheet

The technical specifications in the instructions for use, product data sheets and quotation texts refer to the products manufactured at the time of publication. We are constantly working to improve the performance and efficiency of our products. The goods delivered may therefore deviate slightly from those advertised.
