This is a compact lighting fixture installed on a paved surface, suitable for both outdoor and indoor use.
The light can be directly illuminated to the road surface, no upward light, no glare, suitable for illuminating roads, paths, steps and some
hidden places that need to be illuminated.
Stainless steel 304 lamp body and stainless steel 304 cover.
Ultra white tempered glass.
Silicone gasket.
High efficiency PMMA lens.
Anti-corrosion electrostatic powder coating.
Strengthened PP mounting sleeve.
Internal special air blocking waterproof cable.
| Model | Power | Beam angle | CCT | Luminous flux | Control | SDCM | CRI | LED | Voltage | Weight |
|---|---|---|---|---|---|---|---|---|---|---|
| ET8845 | 5W | 90° | 2700K / 3000K / 4000K / 5000K | 28lm | ON/OFF | 5 | 80 | LEDx1 | 24VDC | 1.3KG |
Electrical and Control
| Voltage | 24VDC |
| Power | 5W |
| Power Supply | Built-in |
| Control | ON/OFF / 0-10V / DALI |
| Cable | 0.5M H05RN-F 3x1mm2 |
| Environmental | -30 °C ~ 50 °C |
LED and Optics
| LED Brand | CITIZEN / CREE |
| LED Quantity | LED X 1 |
| Beam Angle | 90° |
| Delivered Lumen | 28lm |
| Colour Rendering | CRI 80 |
| SDCM | 3 |
| CCT | 2700K / 3000K / 4000K / 5000K |
| LED Optic | PMMA Lens |
Physical
| Housing | Die-cast aluminum |
| Lens Material | Tempered glass |
| External Screw | Stainless steel material |
| Surface Treatment | Anticorrosive coating |
| Net Weight | 1.3KG |
| Warranty | 3 years |
| Rating | IP67 |
| Impact Protection | IK10 |
| Certifications | CE |
