ET8850

  • Product Introduction

Die casting aluminum body.

Ultra white tempered glass.

Silicone gasket.

High efficiency PMMA lens.

Anti-corrosion electrostatic powder coating.

Mounting plate and stainless steel external screws.

Strengthened PP mounting sleeve.

High Power LED chips, constant current driver, line voltage input.

On/off standard, DALI , 0-10V or DMX512 dimming is available.

Specialized anti-water & vapour wiring.

Slip-resistant glass is available for walking area in public.


Model Power Beam angle CCT Luminous flux Control SDCM CRI LED Voltage Weight
ET8850.N 40W 8°/12°/22°/35°/45° 2700K / 3000K / 4000K / 6000K 3040lm（3000K 8°） ON/OFF 5 80 LEDx12 100V-240V 8KG
ET8850 40W 12°/22°/35°/45°/15°*45° 2700K / 3000K / 4000K / 6000K 3307lm（3000K 12°） ON/OFF 5 80 LEDx18 100V-240V 8KG
  • Specifications
  • Download
  • Accessory

ET8850.N

Electrical and Control

Voltage 100V-240V
Power40W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-40 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityLED X 18
Beam Angle8°/12°/22°/35°/45°
Delivered Lumen3040lm（3000K 8°）
Colour RenderingCRI 80
SDCM5
CCT2700K / 3000K / 4000K / 6000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight8KG
Warranty3 years
RatingIP67
Impact ProtectionIK10
CertificationsCE


ET8850.N

Documents

ET8850.N

Optional accessories

  • Specifications
  • Download
  • Accessory

ET8850

Electrical and Control

Voltage 100V-240V
Power40W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-40 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityLED X 18
Beam Angle12°/22°/35°/45°/15°*45°
Delivered Lumen3307lm（3000K 12°）
Colour RenderingCRI 80
SDCM5
CCT2700K / 3000K / 4000K / 5000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight8KG
Warranty3 years
RatingIP67
Impact ProtectionIK10
CertificationsCE


ET8850

Documents

ET8850

Optional accessories

  • Information
  • Downloads
  • Accessories
  • Service

71 025

DALI cross switch

DALI cross switch
sdsdsds

71 025

DALI cross switch

DALI cross switch
Documents

Product data sheet

Product data sheet

The technical specifications in the instructions for use, product data sheets and quotation texts refer to the products manufactured at the time of publication. We are constantly working to improve the performance and efficiency of our products. The goods delivered may therefore deviate slightly from those advertised.
