ET8114

  • Product Introduction

Die casting aluminum body.

Ultra white tempered glass.

Silicone gasket.

High efficiency PMMA lens.

Anti-corrosion electrostatic powder coating.

Mounting plate and stainless steel external screws.

Strengthened PP mounting sleeve.

High Power LED chips, constant current driver, line voltage input.

On/off standard, DALI , 0-10V or DMX512 dimming is available.

Specialized anti-water & vapour wiring.

Slip-resistant glass is available for walking area in public.


Model Power Beam angle CCT Luminous flux Control SDCM CRI LED Voltage Weight
ET8114 22W 8° / 12° / 22° / 35° / 45°/ 15°*45° 2700K / 3000K / 4000K / 5000K 1916lm(3000K 8°) ON/OFF 5 80 LEDx9 220V-240V 4Kg
  • Specifications
  • Download
  • Accessory

ET8114

ET8114

Documents

ET8114.IES

ET8114

Optional accessories

  • Information
  • Downloads
  • Accessories
  • Service

71 025

DALI cross switch

DALI cross switch
sdsdsds

71 025

DALI cross switch

DALI cross switch
Documents

Product data sheet

Product data sheet

The technical specifications in the instructions for use, product data sheets and quotation texts refer to the products manufactured at the time of publication. We are constantly working to improve the performance and efficiency of our products. The goods delivered may therefore deviate slightly from those advertised.
