ET8849

  • Product Introduction

Die casting aluminum body.

Ultra white tempered glass.

Silicone gasket.

High efficiency PMMA lens.

Anti-corrosion electrostatic powder coating.

Mounting plate and stainless steel external screws.

Strengthened PP mounting sleeve.

High Power LED chips, constant current driver, line voltage input.

On/off standard, DALI , 0-10V or DMX512 dimming is available.

Specialized anti-water & vapour wiring.

Slip-resistant glass is available for walking area in public.


Model Power Beam angle CCT Luminous flux Control SDCM CRI LED Voltage Weight
ET8849.N 7W 8°/12°/22°/35°/45°/15°*45° 2700K / 3000K / 4000K / 6000K 501lm（3000K 8°） ON/OFF 5 80 LEDx4 100V-240V 2.6KG
ET8849 7W 8°/12°/22°/35°/45°/15°*45° 2700K / 3000K / 4000K / 6000K 671lm（3000K 8°） ON/OFF 5 80 LEDx6 100V-240V 2.6KG
  • Specifications
  • Download
  • Accessory

ET8849.N

Electrical and Control

Voltage 100V-240V
Power7W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-20 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityLED X 4
Beam Angle8°/12°/22°/35°/45°/15°*45°
Delivered Lumen671lm（3000K 8°）
Colour RenderingCRI 80
SDCM5
CCT2700K / 3000K / 4000K / 6000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight2.6KG
Warranty3 years
RatingIP67
Impact ProtectionIK10
CertificationsCE


ET8849.N

Documents

ET8849.N

Optional accessories

  • Specifications
  • Download
  • Accessory

ET8849

Electrical and Control

Voltage 100V-240V
Power7W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-20 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityLED X 6
Beam Angle8°/12°/22°/35°/45°/15°*45°
Delivered Lumen671lm（3000K 8°）
Colour RenderingCRI 80
SDCM5
CCT2700K / 3000K / 4000K / 6000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight2.6KG
Warranty3 years
RatingIP67
Impact ProtectionIK10
CertificationsCE


ET8849

Documents

ET8849

Optional accessories

  • Information
  • Downloads
  • Accessories
  • Service

71 025

DALI cross switch

DALI cross switch
sdsdsds

71 025

DALI cross switch

DALI cross switch
Documents

Product data sheet

Product data sheet

The technical specifications in the instructions for use, product data sheets and quotation texts refer to the products manufactured at the time of publication. We are constantly working to improve the performance and efficiency of our products. The goods delivered may therefore deviate slightly from those advertised.
