Bollard is a special product that must be exposed to the landscape environment.
With simple design and texture, bollards can integrate with architecture and provide high-quality optical lighting.
It is part of the architectural landscape during the day and provides lighting guidance.
Suitable for villas, park landscape, etc.
Die casting aluminum body.
Ultra white tempered glass.
Silicone gasket.
High efficiency PMMA lens.
Anti-corrosion electrostatic powder coating.
Stainless steel external screws and mounting plate.
The housing height can be customized.
Modular lamp holder, easy to disassemble, rotatable fixing method, locked with one screw, optimized for product aesthetics.
ET can provide up to 10 years of product replacement parts services, continuously optimizing products while also balancing the sustainable use of old products.
Secondary optical design of downward illumination, and Backlight optical reflection is adopted to meet the needs of different scenes. The optical distribution is designed with downward polarization, which will not cause glare and light pollution of parallel viewing angle, and can
achieve 100% efficiency of lighting.
Adopting ultra-high light efficiency reflective optics, avoiding direct light and reducing the presence of glare. Adopting precision scale reflector, it can achieve large-scale flooding and provide product efficiency.
| Model | Power | Beam angle | CCT | Luminous flux | Control | SDCM | CRI | LED | Voltage | Weight |
|---|---|---|---|---|---|---|---|---|---|---|
| ET5089-500mm | 26W | 360° | 2700K / 3000K / 4000K | 1232lm | ON/OFF | 5 | 80 | SMDx48 | 220V-240V | 7.2Kg |
| ET5028-800mm | 26W | 360° | 2700K / 3000K / 4000K | 1232lm | ON/OFF | 5 | 80 | SMDx48 | 220V-240V | 8.9Kg |
Electrical and Control
| Voltage | 220V-240V |
| Power | 26W |
| Power Supply | Built-in |
| Control | ON/OFF / 0-10V / DALI |
| Cable | 0.5M H05RN-F 3x1mm2 |
| Environmental | -20 °C ~ 50 °C |
LED and Optics
| LED Brand | OSRAM |
| LED Quantity | SMDx48 |
| Beam Angle | 360° |
| Delivered Lumen | 1232lm |
| Colour Rendering | CRI 80 |
| SDCM | 5 |
| CCT | 2700K / 3000K / 4000K |
| LED Optic | PMMA Lens |
Physical
| Housing | Die-cast aluminum |
| Lens Material | Tempered glass |
| External Screw | Stainless steel material |
| Surface Treatment | Anticorrosive coating |
| Net Weight | 7.2KG |
| Warranty | 3 years |
| Rating | IP65 |
| Impact Protection | IK06 |
| Certifications | CE |
Electrical and Control
| Voltage | 220V-240V |
| Power | 26W |
| Power Supply | Built-in |
| Control | ON/OFF / 0-10V / DALI |
| Cable | 0.5M H05RN-F 3x1mm2 |
| Environmental | -20 °C ~ 50 °C |
LED and Optics
| LED Brand | OSRAM |
| LED Quantity | SMDx48 |
| Beam Angle | 360° |
| Delivered Lumen | 1232lm |
| Colour Rendering | CRI 80 |
| SDCM | 5 |
| CCT | 2700K / 3000K / 4000K |
| LED Optic | PMMA Lens |
Physical
| Housing | Die-cast aluminum |
| Lens Material | Tempered glass |
| External Screw | Stainless steel material |
| Surface Treatment | Anticorrosive coating |
| Net Weight | 8.9KG |
| Warranty | 3 years |
| Rating | IP65 |
| Impact Protection | IK06 |
| Certifications | CE |
