ET6903

  • Product Introduction

Side Bend Series.The maximum length can be 5m.

Using optical grade environmental protection silicone material, salt resistance, acid and alkali corrosion resistance, UV resistance.

The free bending structure design can perfectly fit the outdoor curved surface of various arcs to achieve the effect of wall washing.

Integrated extrusion molding process, waterproof grade up to IP65.

Patented optical structure design, a variety of angles optional.

Hidden end cap design, easy to install.


Model Power Beam angle CCT Luminous flux Control SDCM CRI LED Voltage Weight
ET6903 10W/m 120° 2700K / 3000K / 4000K / 5000K 830lm ON / OFF 5 80 SMDx80 24VDC 0.38KG
  • Specifications
  • Download
  • Accessory

ET6903

Electrical and Control

Voltage24VDC
Power10W/m
Power SupplyRemote
ControlON/OFF / 0-10V / DALI
Cable0.2M H05RN-F 3x1mm2
Environmental-20 °C ~ 40 °C


LED and Optics

LED BrandOSRAM
LED QuantitySMDx80
Beam Angle120°
Delivered Lumen830lm
Colour RenderingCRI 80
SDCM5
CCT2700K / 3000K / 4000K / 5000K
LED OpticPMMA Lens


Physical

HousingUsing optical grade environmental protection silicone material
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight0.38KG
Warranty3 years
RatingIP65
Impact ProtectionIK05
CertificationsCE




ET6903

Documents

ET6903

Optional accessories
